BAUDECK slab formwork

A modern panel slab system for fast slab formwork.

The lightweight aluminium structure and durable birch plywood ensure that the formwork withstands high loads. Ideal if you are looking for formwork for quick slab construction.

Low weight

One person can carry a single panel.

Rapid striking

Striking the slab without lowering the props.

Compatible with Topec

Can be combined with Topec-type panels.

Switch between sections by clicking on the tabs.

System for
fast slab formwork

Baudeck BAUDECK slab formwork is a lightweight and versatile panel slab formwork, ideal for a wide range of applications in construction, especially in large-area projects. The low weight and the ability to adjust panels to the surface allow for quick assembly of the formwork. Dismantling is facilitated by drop heads, thanks to which there is no need to lower the props.

Technical specifications

Panel widths

45/60/75/90/180 cm

Panel heights

90/120 cm

Adjustable panels

55–90 × 90 cm / 55–90 × 180 cm

Frame

powder-coated 14 cm aluminium profile

Average weight

panel 90×90 cm = 16.00 kg, 90×180 cm = 27.00 kg, 180×180 cm = 53.14 kg

Sheathing

birch plywood

Compatibility

Topec

Are you interested in BAUSCHAL? Contact us using phone or WhatsApp.

Make a call

+48 570 555 579

Write on WhatsApp

Send a message

How does BAUDECK stand out from other slab formworks?

Adjustable panel dimensions

Thanks to the 15 cm panel width, BAUDECK formwork can be precisely adjusted even to the most complex slab. Special UNI panels unfold, filling the surface with an infill section with a width of 55–90 cm and a length of 90 cm or 180 cm.

Fast assembly and dismantling

A wide range of panel and beam sizes allows adaptation to virtually any slab layout, eliminating the need for additional infill elements. The use of a drop head enables early striking of the slab without dismantling the props, resulting in significant time and cost savings compared to traditional beam-based systems.

Compatible with popular slab props

When equipped with system heads, BAUDECK can be used with commonly available slab props, class B and above, in accordance with EN 1065.

Powder-coated aluminium frame

The frame consists of a 14 cm high aluminium profile with 73 mm cross members and 2 mm wall thickness. The powder-coated finish facilitates cleaning and reduces concrete adhesion.

10 mm birch plywood facing

The facing is made of high-quality waterproof birch plywood, fixed with rivets for quick replacement in case of damage.

Easy storage and transport

The system can easily be converted into a pallet by turning the BAUDECK panel plywood-side down and installing folding corner brackets. This creates a storage and transport pallet capable of holding 7 panels. It can be handled by crane or forklift. Each corner bracket has a load capacity of 400 kg.
